Parameterizing Steps 05.2006
6SE7087-2JD60 Siemens AG
9-12 Operating Instructions SIMOVERT MASTERDRIVES
P101 = ?
Enter the rated motor voltage in V
as per rating plate
P102 = ?
Enter the rated motor current in A
as per rating plate
(group drives: total of all motor currents)
1
2
P104=?
IEC motor: Cos (phi)
as per rating plate
NEMA motor: nominal rating [Hp]
(group drives: total of all ratings)
P105=?
NEMA motor: Enter the motor efficiency in %
as per rating plate
P106=?
P107 = ?
Enter the rated motor frequency in Hz
as per rating plate
3
4
P108 = ?
Enter the rated motor speed in rpm
as per rating plate
P109 = ?
Enter the motor pole pair number
(is automatically calculated)
5
SIEMENS
1LA7133-4AA10
Nr.E H984 6148 01 002
EN 60034 Th.Cl. F
3 ~Mot.
IP 55
132 M/IM B3
50 Hz 230 / 400V
/
D
7.5 kW 26.5 / 15.3 A
cos
0.82 1455 / min
220-240 / 380-420 V /
26.5-27.0 / 15.3-15.6 A
SF 1.1
60 Hz 460 V
8.6 kW 14.7 A
cos
0.83 1755 / min
440/480 V
15.0-15.2 A
C E
2
3
1
4
5
P114 = ?
WARNING!
INCORRECT SETTINGS CAN BE DANGEROUS!
For vector control only:
Process-related boundary conditions for control
0: Standard drives (default)
1: Torsion, gear play
2: Acceleration drives
3: Load surge
4: Smooth running characteristics
5: Efficiency optimization
6: Heavy-duty starting
7: Dynamic torque response in field-weakening range
See "Drive setting" section for description
P100=1,2
