Siemens Vector Control User Manual

Parameterizing Steps 05.2006
6SE7087-2JD60 Siemens AG
9-20 Operating Instructions SIMOVERT MASTERDRIVES
87654321
Setpoint source
MASTERDRIVES VCAnalog input and terminal strip (P368=1)
- s1 -
B0016 B0018 B0020 B0022
P561.1 (16)
B
P567.1 (18)
B
P555.1 (20)
B
P554.1 (22)
B
Src3 Acknowledge
Src ON/OFF1
/6 /7 /8
<1>
Analog inputs
Sheet [80] / sheet [82]
P654.1
B
Src1 OFF2
Terminal strip
Sheet [90]
/5 /4 /3 /2 /1
B0014
P653.1 (0)
B
B0012
P652.1 (104)
B
B0010
P651.1 (107)
B
M24
P24
-X101
B0104 B0107
operation
0=fault
*
)
*
)
*
)
If used as digital inputs, the parameters P651.B, P652.B, P653.B and P654.B have to be set to 0! If used as digital outputs, B10 to B14 must not be wired.
*
)
1=operation
no fault
*
)
<2>
D
A
AnaIn1 Smoothing
P634.1
AnaIn1 Offset
P631.1
<3>
Analog input 1
AnaIn1 Setpoint
r637.1
K0011
AnaIn1 Setpoint
P443.B (11)
KK
Src Main setpoint
X102/17
D
A
AnaIn2 Smoothing
P634.2
AnaIn2 Offset
P631.2
X102/18
Analog input 2
AnaIn2 Setpoint
r637.2
K0013
AnaIn2 Setpoint
P486.B (11)
KK
Src.T setpoint
AnaIn Conf. CUVC P632 S3
switch
0 -10 ... 10 V open 1 -10 ... 10 V 2 -20 ... 20 mA 3 -20 ... 20 mA closed 4 -04 ... 20 mA
0-10 ... 10 V
corresponds to
-100 .... 100 %
(only T-control)
from sheet [200] to sheet [180]
N
to sheet[316.1] to sheet[320.1]
M
n959.82 = 4
Src Inv Release
Setting guide for gain and offset of setpoint frequency/ speed values:
sheet[316]
Compact PLUS Jumper on EBV S3 switch
5 - 6 4 - 5
<1> Compact/Chassis type unit:
Compact PLUS type unit:
Terminal X101/9 Terminal X102/19
<2> Compact/chassis type unit:
Compact PLUS type unit:
Terminal X102/15 Terminal X101/9
<3> Compact/Chassis type unit:
Compact PLUS type unit:
Terminal X102/16 Terminal X101/10
