Siemens Vector Control User Manual

Control Word and Status Word 05.2006
6SE7087-2JD60 Siemens AG
10-8 Operating Instructions SIMOVERT MASTERDRIVES
Bit 28: Command, external alarm 1 (L "External alarm 1")
LOW signal
♦ The operating status is maintained. An alarm message is issued
(A015).
Bit 29: Command, external alarm 2 (L "External alarm 2")
LOW signal
♦ The operating status is maintained. An alarm message is issued
(A016).
Bit 30: Select, BICO data sets (H "data set 2") / (L "data set 1")
HIGH signal
♦ The parameter settings of data set 2 for all binector and connector
commands and signals, are activated.
LOW signal
♦ The parameter settings of data set 1 for all binector and connector
commands and signals, are activated.
Bit 31: Main contactor checkback signal command (H "main contactor checkback
signal")
HIGH signal, corresponding to the wiring and parameterization of the
main contactor (option). The checkback time can be set in P600.
♦ Checkback signal, "main contactor energized" (closed).
Condition
Result
Condition
Result
Condition
Result
Condition
Result
Condition
Result
