3 On/Off Yellow (28 AWG)
On/Off: Control line to turn the gateway on and off. Pin
3 must be connected: either to the input power source
or to an on/off switch. The FX30 is off when this pin is
low, but you also have to option to monitor this pin
using GPIO 24, and holding the power on while a
Legato-designed application executes. For more
information, see OFF Mode on page 47.
4 IO 1 Brown Digital input
Wake from low power modes
a
Internal pull-up control
5 IO 2 Green Digital input
Wake from low power modes
Internal pull-up control
Analog input
6 IO 3 Orange Digital input
Internal pull-up control
Digital output
Note: See Table D-1, FX30 Hardware Feature to Linux Interface Mapping, on page 74
for the radio module GPIO and Linux interface mapping of pins 3 to 6.
a. For more information on power modes, see Power Modes on page 47.
Table 2-1: Power Connector Pin and DC Cable Wires
Pin Function Associated
DC Cable
Wire Color
Description
