Sierra Wireless FX30 - Mechanical Specifications

Specifications
Rev 4 March 2019 45 41110030
Mechanical Specifications
Figure 3-1: FX30 Mechanical Specifications
Top view
Weight: 158 g (5.57 oz.)
Dimensions (l × w × h)
75 × 60 × 32 mm (excluding connectors)
82 × 60 × 32 mm (including connectors)
82 mm
75 mm
SIM card/IoT card cover
GNSS antenna connector
Cellular antenna connector
USB
Ethernet (FX30 only.
Power connector
End views
60 mm
LEDs
FX30S has a serial port)
