Specifications
Rev 4 March 2019 51 41110030
Internet of Things (IoT) Expansion Card
The FX30 is compatible with single slot, category 1 (14 mm maximum), power
category 1 and 2 IoT Expansion cards. The IoT connector has 38 pins and
supports the following interfaces:
• 1 × ADC
• 4 × GPIO
• 1 × I2C
• 1 × PCM
• 1 × SPI
• 1 × UART
• 1 × USB
• 1 × SDIO
Active Full
Function GSM
Max Tx power (+33 dBm)
USB 110 Mbps
Ethernet 94 Mbps
24 195 4686 274 6584
12 357 4282 622 7461
4.5 918 4133 1560 7022
Active Full
Function LTE
Max Tx power (+33 dBm)
USB 110 Mbps
Ethernet 94 Mbps
24 174 4184 290 6971
12 319 3824 658 7900
4.5 820 3690 1652 7435
Table 3-17: Power Consumption — Active Mode FX30 Cat-M (WP7702)
Mode Conditions Voltage Max continuous Burst
V mA mW mA mW
Table 3-18: Power Consumption — Off and Ultra Low Power Modes
Mode Conditions Voltage Maximum continuous
V µA µW
Off On/Off is set to Off 24 13 312
12 33 396
4 67 268
Ultra Low Power Triggering timer 24 165 3960
12 170 2040
4 348 1392
