Sierra Wireless FX30 User Guide
Rev 4 March 2019 50 41110030
Table 3-15: Power Consumption — Active Mode FX30 Cat-1 (WP7603-1)
Mode Conditions Voltage Max continuous Burst
V mA mW mA mW
Active Idle USB and Ethernet cables are
plugged in
24 56 1364 236 5672
12 114 1371 532 6382
4.5 254 1141 1339 6027
Active Full
Function LTE
Max Tx power (+33 dBm)
USB 110 Mbps
Ethernet 94 Mbps
24 226 5420 317 7611
12 419 5034 719 8625
4.5 1113 5007 1804 8118
Active Full
Function
HSDPA
Max Tx power (+33 dBm)
USB 110 Mbps
Ethernet 94 Mbps
24 195 4686 306 7347
12 363 4366 693 8327
4.5 954 4292 1741 7837
Table 3-16: Power Consumption — Active Mode FX30 Cat-1 (WP7607-1)
Mode Conditions Voltage Max continuous Burst
V mA mW mA mW
Active Idle USB and Ethernet cables are
plugged in
24 94 2254 TBD
12 183 2195 TBD
4.5 439 1977 TBD
Active Full
Function LTE
Max Tx power (-18 dBm)
USB 103 Mbps
Ethernet 85 Mbps
24 112 2680 TBD
12 209 2511 TBD
4.5 542 2441 TBD
Table 3-17: Power Consumption — Active Mode FX30 Cat-M (WP7702)
Mode Conditions Voltage Max continuous Burst
V mA mW mA mW
Active Idle USB and Ethernet cables are
plugged in
24 56 1364 236 5672
12 114 1371 532 6382
4.5 254 1141 1339 6027
