Sierra Wireless FX30 User Guide
Rev 4 March 2019 38 41110030
Network
Technology
LTE, HSPA+
GSM /GPRS / EDGE
For lists of supported bands, see Radio Frequency Bands on
page 39.
Host Interfaces Antenna connectors • Cellular
• GNSS
USB • USB 2.0 micro-B connector complies with USB Version 2.0 for
high speed operation
• Sierra Wireless recommends you:
• Use a USB 2.0 cable
• Connect directly to your computer for best throughput.
Ethernet • 10/100 Base-T RJ-45 Ethernet
• Auto-crossover support
• Auto-negotiation, full- and half-duplex
• Not software configurable
IoT (Internet of
Things) Connector
See Internet of Things (IoT) Expansion Card on page 51.
SIM Card Interface • Mini-SIM (2FF) SIM card operated at 1.8 V/3.3 V.
Input / Output
For more information, see page 25.
• Configurable I/O
• Wakeup on I/O, serial, or cellular events
Power Adapter Pins 6-Pin connector:
• Power
• Ground
• On/Off
• I/O1
• I/O2
• I/O3
LEDs
See LED Behavior on page 30.
2 LEDs:
• Power
• User configurable
Mechanical Specifications
For mechanical drawings, dimensions, and
weight, see Mechanical Specifications on
page 45.
• Housing—The FX30 is made of ruggedized powder-coated
aluminum.
• RoHS2—The FX30 complies with the Restriction of Hazardous
Substances Directive 2011/65/EU (RoHS2). This directive
restricts the use of hazardous materials in the manufacture of
various types of electronic and electrical equipment.
Screw Torque Settings • Mount screws
1.1 N-m (10 in-lb)
• Antennas
Finger tight (5–7in-lb.) is sufficient and the max torque should
not go beyond 1.1 N-m (10 in-lb).
Operating Voltage 4.75 to 32 VDC
Table 3-1: Specifications (Continued)
To Next Page
