Functional Description
AP05 Date: 22.08.2022 Art. No. 90885 Mod. status 108/22 Page 12 of 50
Bit
Meaning
Value= 0
Value= 1
11
bs11_BatteryState
Battery
Charging state is OK
Battery
Charging state is critical
12
bs12_SpeedError
There is no SpeedError
There is a SpeedError
13
bs13_KeyConfiguration
Button is not pressed
Button is pressed
14
bs14_KeyCalibration
Button is not pressed
Button is pressed
15
bs15_KeyIncremental
Button is not pressed
Button is pressed
Table 5: StatusWord in Absolute Position operating mode
3.1.2 Alpha-numeric display operating mode
Two 5-digit target values can be displayed in this operating mode. The target values are
acknowledged by pressing the button (see chapter 2.3).
Alpha-numeric display:
Both lines are freely writable. The content of the display line can be transmitted via the
DisplayData parameter, and the content of the display line can be transmitted via the
TargetValue parameter. In ControlWord, the values must be switched to valid (see e. g.,
bc09_TargetValueActive) and the bits for data identification must be set correctly (see e. g.,
bc07_TargetValueTypeSelect). The data identifier is used to distinguish whether the data is
interpreted and displayed as a number or as an alphanumeric character (ASCII)
(see chapter 4.1.1, 4.1.3 and 4.1.5).
LCD display:
If there is no valid target value, the 1st display line is displayed blank. "" appears in the
2
nd
display line.
A valid target value is displayed flashing until its receipt is acknowledged. If neither target
value has been acknowledged, both values are acknowledged jointly by pressing the key.
Acknowledgment can also take place via the corresponding control bit via the interface.
LED display:
Status LED1 and LED2:
With factory settings, the LED display (LED1, LED2) works according to the following table:
Operating state
State
Meaning
There is no valid target value.
Both LEDs off
There is a valid target value.
LED1 red
Display data not acknowledged.
LED1 green
Display data acknowledged.
LED2 red
Target value not acknowledged.
LED2 green
Target value acknowledged.
Table 6: Status LED display in the alpha-numeric display operating mode
