Siko AP05 User Manual

IO-Link
AP05 Date: 22.08.2022 Art. No. 90885 Mod. status 108/22 Page 42 of 50
Fig. 7: Example representation in IO-Link master
5.1.1 Process data in Absolute position operating mode
Sub-index
Significance
(Absolute Position operating mode)
Bit offset
Octet
Length
In (to master)
Out (from master)
1
PositionValue
TargetValue
0
4 … 7
32
2
Reserviert
Reserviert
32
2 … 3
16
3 … 18
StatusWord
ControlWord
48
0 … 1
16
Table 22: Process data definition
5.1.1.1 Process data output (master  device)
Sub-
index
Name
Bit
offset
Bit
length
Data
type
Comment
1
TargetValue
0
32
Signed-
Integer
Absolute target value
2
Reserved
32
16
-
Used in DisplayMode
3
bc00_CalibrationExecute
48
1
Bool
If true calibration
becomes executed
4
bc01_Reserved
49
1
Bool
5
bc02_Reserved
50
1
Bool
Used in DisplayMode
6
bc03_DisplayRange
51
1
Bool
If true display range is
extended
7
bc04_GuardingBit
52
1
Bool
Communication guarding
