Functional Description
AP05
Date
:
22
.08.2022
Art.
No
.
90885
Mod. status
108
/
22
Page
17
of
50
3.3.1.5
"Changeable
parameters" menu
The "Changeable p
arameter
s" menu is structured
as follows:
Description
Display
Page
Positioning
POIt
17
Visualization
IIO
17
LED function
D
18
Device options
OPIO
18
Table 9
:
"Changeable p
arameters" m
enu structure
3.3.1.6
Positioning
The following par
ameters c
an be set in the "Po
sitioni
ng" menu:
Description
Display
Chapter
Resolution
O
4.2.1
DecimalPlaces
P
4.2.2
DisplayDivisor
DDI
4.2.3
CountingDirect
ion
rott
4.2.4
CalibrationValue
CAI
4.2.5
Calibration
selection
CAI
o
3.4
TargetWindow
r1
4.2.6
LoopType
OOP
4.2.7
LoopLength
OOP
4.2.8
Table 10
:
"Positionin
g" menu
3.3.1.7
Visualization
The following par
ameters c
an be set in the "V
isualization" m
enu:
Description
Display
Chapter
DisplayOrientation
DIP
4.3.1
Table 11
:
"Visualization
" menu
16
18
Table of Contents
Table of Contents
2
General Information
5
Documentation
5
History
5
Definitions
5
Intended Use
5
Switching on the Operating Voltage
6
Display and Control Elements
6
LCD Display
6
Extended Display Range
7
LED Display
7
Device Status
7
Communication State
7
Control Keys
8
Key Lock and Enable Time
8
Functional Description
8
Operating Modes
8
Absolute Position Operating Mode
8
Positioning
8
Loop Positioning
10
Controlword in Absolute Position Operating Mode
10
Statusword in Absolute Position Operating Mode
11
Alpha-Numeric Display Operating Mode
12
Controlword: Alpha-Numeric Display
13
Statusword: Alpha-Numeric Display
13
Battery Buffering
14
Parameterization of the Position Indicator
14
Manual Parameterization
15
Starting Parameterization
15
Value Input
15
Value Selection
15
Overview of the Operating Menu
16
Changeable Parameters" Menu
17
Positioning
17
Visualization
17
LED Function
18
Device Options
18
Parameterization Via Interface
18
Calibration
18
Additional Functions
19
Device Information
19
Diagnosis
19
Reading the Error Memories
19
Presentation
20
Restore Factory Settings
20
Operation Hours Counter
20
General Operating Hours Counter
20
Customer-Specific Operating Hours Counter
21
Warnings / Errors
21
Warnings
21
Errors
22
Error Memory
22
Error Counter
23
Corrective Actions
23
Adjustment Run (Already Carried out at the Factory for AP05)
23
Parameter
24
Process Data
24
Controlword
24
Statusword
24
Targetvalue
25
Actualvalue
25
Displaydata
26
Targetvalueleft
26
Positioning
26
Resolution
26
Decimalplaces
27
Displaydivisor
28
Countingdirection
28
Calibrationvalue
29
Targetwindow
29
Looptype
30
Looplength
30
Visualization
31
Displayorientation
31
Leds
31
Ledmode
31
Led1Greenmode
32
Led2Greenmode
32
Led1Redmode
33
Led2Redmode
33
Activeledsflashing
34
Device Options
34
Keyenabletime
34
Keycalibration
35
Keyincremental
35
Operatingmode
36
Pinchange
36
Loaddefault
37
Code
37
Error Counter
37
Event Counter for the Error "Battery Dead
38
Event Counter for the Error "Permissible Travel Speed Exceeded
38
Event Counter for the Error "Sensor Error, Magnetic Field Faulty
39
Event Counter for the Error "Sensor Error, Reader Head Faulty
39
Event Counter for the Error "Sensor Error, sin COS Monitoring
39
Event Counter for the Error "Sensor Error, Internal Error3
40
Event Counter for the Error "Sensor Error, Internal Error4
40
IO-Link
41
Process Data Input / Output
41
Process Data in Absolute Position Operating Mode
42
Process Data Output (Master Device)
42
Process Data Input (Device Master)
43
Process Data in Alphanumeric Display Operating Mode
44
Process Data Output (Master Device)
44
Process Data Input (Device Master)
45
Directory of Objects
46
IO-Link Specific Objects
46
Systemcommands
47
Deviceaccesslocks
47
Eventcodes
47
Errorcodes
48
Block Diagram
49
