Functional Description
AP05 Date: 22.08.2022 Art. No. 90885 Mod. status 108/22 Page 18 of 50
3.3.1.8 LED function
The following parameters can be set in the "LED function" menu:
Description
Display
Chapter
Led1GreenMode
Gr1
4.4.2
Led2GreenMode
Gr
4.4.3
Led1RedMode
D1
4.4.4
Led2RedMode
D
4.4.5
ActiveLedsFlashing

4.4.6
Table 12: "LED function" menu
3.3.1.9 Device options
The following parameters can be set in the "Additional device options" menu:
Description
Display
Chapter
KeyEnableTime
D
4.5.1
KeyCalibration
CAn
4.5.2
KeyIncremental
Incn
4.5.3
OperatingMode
OPt
4.5.4
PinChange
PI
4.5.5
LoadDefault
OADP
4.5.6
CODE
COD
4.5.7
Table 13: "Additional device options" menu
3.3.2 Parameterization via interface
The position indicator can be completely parameterized in the IO-Link interface
(see chapter 5.2).
3.4 Calibration
Calibration is only possible if the chain dimension is not active and the
actual value is not 0.
Two steps are required for executing calibration:
• Write calibration value: Parameter CalibrationValue (see chapter 4.2.5).
• Execute calibration (using operating keys, see chapter 2.3 and 3.3.1 or SystemCommand
see chapter 5.3 or ControlWord see chapter 5.1.1.1).
During calibration using the control buttons, a countdown of 5 seconds is started and
displayed. Calibration is completed after the countdown.
