Functional Description
AP05
Date: 22.08.2022 Art. No. 90885 Mod. status 108/22 Page 19 of 50
During calibration, the calibration value is used to calculate the actual value. The following
applies at this time:
Actual value = ActualValue = 0 + CalibrationValue
Since the measuring system is an absolute system, calibration is necessary only once with
commissioning.
3.5 Additional functions
3.5.1 Device information
The following values can be read in the "Read Only" menu:
Table 14: "Device data" menu
3.5.2 Diagnosis
The AP05 features various diagnostic options, which can be selected from the "Diagnosis"
submenu. The following diagnostic options are differentiated:
Reading the error memories
Table 15: "Diagnosis" menu
3.5.2.1 Reading the error memories
Two different error histories can be output here.
The "AP05" list contains errors found by the device such as "Low battery voltage" or "Velocity
exceeded".
With errors occurring, the error number and overall quantity are output on the upper line. The
type of error appears in the lower line, with error number 1 containing the latest error. The
oldest error is output with the highest error number. "norr" appears if no errors have been
detected so far.
