Siko AP05 User Manual

IO-Link
AP05 Date: 22.08.2022 Art. No. 90885 Mod. status 108/22 Page 43 of 50
Sub-
index
Name
Bit
offset
Bit
length
Data
type
Comment
8
bc05_ErrorAck
53
1
Bool
If true the actual error is
acknowledged
9
bc06_Reserved
54
1
Bool
Used in DisplayMode
10
bc07_Reserved
55
1
Bool
Used in DisplayMode
11
bc08_Reserved
56
1
Bool
Used in DisplayMode
12
bc09_TargetValueActive
57
1
Bool
If true TargetValue is
active
13
bc10_Reserved
58
1
Bool
14
bc11_Led1Green
59
1
Bool
If true LED is on. Function
controlled via Parameter
LEDMode
15
bc12_Led1Red
60
1
Bool
see bc11
16
bc13_Led2Green
61
1
Bool
see bc11
17
bc14_Led2Red
62
1
Bool
see bc11
18
bc15_LedBlinking
63
1
Bool
If true LEDs are blinking
when on
Table 23: Process data output in Absolute position operating mode
5.1.1.2 Process data input (device  master)
Sub-
index
Name
Bit
offset
Bit
length
Data
type
Comment
1
PositionValue
0
32
Signed-
Integer
Absolute position value
2
Reserved
32
16
-
3
bs00_DirIndicationCW
48
1
Bool
True if indicator cw is on
4
bs01_DirIndicationCCW
49
1
Bool
True if indicator ccw is on
5
bs02_CalibrationExecuted
50
1
Bool
True if calibration was
executed by command via
interface
6
bs03_Reserved
51
1
Bool
Used in DisplayMode
7
bs04_GuardingBit
52
1
Bool
Communication guarding
8
bs05_TargetWindowReached
53
1
Bool
True if target window is
reached
9
bs06_Deviation
54
1
Bool
Deviation from actual
value to target
10
bs07_GeneralError
55
1
Bool
True if error occurred
11
bs08_Reserved
56
1
Bool
Used in DisplayMode
12
bs09_IncMeasurement
57
1
Bool
True if incremental
measurement is active
13
bs10_TargetValueState
58
1
Bool
True if target value is
active
