Siko AP05 - Systemcommands; Deviceaccesslocks; Eventcodes

IO-Link
AP05 Date: 22.08.2022 Art. No. 90885 Mod. status 108/22 Page 47 of 50
Index
(hex)
Name
Type
Length
Access
Default
Comment
36
(24h)
DeviceStatus
Uint
1 Byte
ro
See IO-Link
Interface Spec.
Table 28: IO-Link specific indexes
5.3 SystemCommands
Index
(hex)
Name
Access
Value
Name
Comment
2 (02h)
SystemCommands
wo
1
ParamUploadStart
IO-Link Spec.
2
ParamUploadEnd
3
ParamDownloadStart
4
ParamDownloadEnd
5
ParamDownloadStore
6
ParamBreak
128
Device Reset
130
Restore factory
settings
160
Start Alignment
161
Enable bootloader
Bootloading not
via IO-Link
252
Execute calibration
See chapter 3.4
Table 29: SystemCommands
5.4 DeviceAccessLocks
Index
(hex)
Name
Access
Supported Access Locks
Comment
12 (0Ch)
DeviceAccessLocks
rw
Data Storage
IO-Link Spec.
Local Parameterization
IO-Link Spec.
Table 30: DeviceAccessLocks
5.5 EventCodes
See also chapter 3.6.2.
Value
Name
Type
Comment
6145 (1801h)
Speed error
Error
Travel speed exceeded
6146 (1802h)
Battery empty
Error
Battery undervoltage (dead)
6158 (180Eh)
Internal error 3
Error
Sensor error, internal error3
6159 (180Fh)
Internal error 4
Error
Sensor error, internal error4
