Functional Description
AP05 Date: 22.08.2022 Art. No. 90885 Mod. status 108/22 Page 22 of 50
Display
Bit assignment in the StatusWord
Error
flashing
bs11_BatteryState
Low battery voltage (critical)
PositionValue is still valid!
Table 17: Warnings
3.6.2 Errors
Calibration may also be required Depending on the error type.
Error states are signaled via display (written in red or battery symbol) and interface. The
cause of the fault can be determined using the event or error code (see chapter 5.5 and 5.6).
To return to normal operation, the cause must be removed (see Table 18). Error signaling can
then be acknowledged or deleted with the - Taste (see chapter 2.3) key.
(For signaling see chapter 2.1.)
Display
Bit assignment in the StatusWord
Error
permanent
bs11_BatteryState +
bs07_GeneralError
Battery undervoltage (dead)
PD
bs12_SpeedError +
bs07_GeneralError
Travel speed exceeded
Table 18: Error messages in the display
3.6.2.1 Error memory
All occurring error messages are entered in the error memory in the sequence in which they
are recorded. When the error memory is full, the last 10 error messages are displayed. Error
memory is deleted when the factory settings are restored.
The stored errors can be output in the diagnostic function (see chapter 3.5.2.1) via the LCD
display. The display has the following meaning:
In the 1
st
line shows the current error and the total number of stored errors.
2
nd
line:
Display
Error
Ato
Battery dead
P
Permissible travel speed exceeded
n
Sensor error, magnetic field faulty
non
Sensor error, reading head faulty
nr
Sensor error, SIN COS monitoring
nIC
Sensor error, internal error
tor
Data memory faulty
