Siko AP05 - Process Data in Alphanumeric Display Operating Mode; Process Data Output (Master  Device)

IO-Link
AP05 Date: 22.08.2022 Art. No. 90885 Mod. status 108/22 Page 44 of 50
Sub-
index
Name
Bit
offset
Bit
length
Data
type
Comment
14
bs11_BatteryState
59
1
Bool
True if battery state is
critical or low
15
bs12_SpeedError
60
1
Bool
True if max speed was
exceeded
16
bs13_KeyConfiguration
61
1
Bool
True if key is actuated
17
bs14_KeyCalibration
62
1
Bool
True if key is actuated
18
bs15_KeyIncremental
63
1
Bool
True if key is actuated
Table 24: Process data input in Absolute position operating mode
5.1.2 Process data in Alphanumeric display operating mode
Sub-index
Significance (Alphanumeric display
operating mode)
Bit offset
Octet
Length
In (to master)
Out (from master)
1
ActualValue
TargetValue
0
4 … 7
32
2
Reserviert
TargetValueLeft
32
2 … 3
16
3 … 18
StatusWord
ControlWord
48
0 … 1
16
Table 25: Process data definition
5.1.2.1 Process data output (master  device)
Sub-
index
Name
Bit
offset
Bit
length
Data
type
Comment
1
TargetValue
0
32
Signed-
Integer
Displayed value in bottom
row (4 figures right)
2
TargetValueLeft
32
16
Unsigned
Integer
Displayed value in bottom
row (2 figures left)
3
bc00_Reserved
48
1
Bool
Used in AbsoluteMode
4
bc01_Reserved
49
1
Bool
If true DisplayData is
active
5
bc02_DisplayDataActive
50
1
Bool
6
bc03_DisplayRange
51
1
Bool
If true display range is
extended
7
bc04_GuardingBit
52
1
Bool
Communication guarding
8
bc05_ErrorAck
53
1
Bool
If true the actual error is
acknowledged
9
bc06_TargetValueAckMode
54
1
Bool
If true TargetValue
becomes acknowledged
10
bc07_TargetValueTypeSelect
55
1
Bool
Format of TargetValue
11
bc08_DisplayDataTypeSelect
56
1
Bool
Format of DisplayData
