added together to calculate the total current on the battery. Set this value to OFF
for all the other shunts.
Example 1: One sensor may monitor the total current on the battery, and other
sensors may be used to monitor certain consumers or generators. Set this value to
ON for the sensor which monitors the total current on the battery. Set this value to
OFF for all the other sensors.
Example 2: Three shunts may be connected to the battery in parallel, to monitor
the consumption in three different branches. To calculate the total current on the
battery, the currents of all three shunts must be added together. In such scenario,
set the value to ON for all three shunts.
8.3.4.5 BATTERY
Used to select the battery to which the sensor is connected to.
8.3.4.6 DISPLAY PRIORITY
This setting enables you to choose between the following display priorities: HIGH,
MEDIUM, LOW and HIDE.
The display priority is used for ordering the current sensors on PICO’s screen.
When current sensors are shown on the screen, those with HIGH display priority
are shown first (at the top), followed by sensors with MEDIUM display priority.
Sensors with LOW display priority are shown last (at the bottom). If you select
HIDE, this sensor will not be shown on the Batteries screen (it will be hidden).
