Simmons SD9K - Audio and Power Connections; Audio Equipment Setup; Power Supply and Switch

www.simmonsdrums.net
13
audio equipment
headphones
mp3/cd player
power supply
power switch
WhenusinganampliersuchastheSimmonsDA50orDA200S,
connecttheOutputL/MONOandRjacksontherearpaneltothe
inputoftheamplier.(Formonoplayback,usetheL/MONOjack;
forstereoplayback,connectbothL/MONOandRjacks.)
ThelineoutputvolumeiscontrolledbytheMAINOUT
volumeknob.
Anoptionalsetofstereoheadphonescanbeconnectedtothe
PHONESjacklocatedonthesideofthedrummodule.
TheheadphonesoutputvolumeiscontrolledbythePHONES()
volumeknob.
1.ConnecttheaudiooutputofanMP3/CDplayerorotheraudio
sourcetothestereoAUXINTRSjackontherearpanel.
2. The input signal is mixed with the drum signal,
allowing you to play along.
ThevolumeoftheexternalsourceiscontrolledbytheAUXIN
volumeknob.
MakesurethepowerisswitchedOFF.Connectthepoweradapter
totheDCINjackontherearpanel.
NOTE:
MakesurethepowerisswitchedOFFwhenconnectingthe
drum module with external devices.
Afterconrmingthatallconnectionshavebeencompleted,
rotatethevolumeknobtotheleft(minimumvolumelevel)
before switching the power on.
Setthepowerswitchtothe“ON”position.TheKitindicator
willlightupandthedisplaywillshowKitnumber001.
Caution:Afterthepoweristurnedon,theSimmonslogowill
appearforafewseconds,andthentheDrumKitnamewill
appear.DonotpressanypadorpedaluntiltheKitindicatorturns
on.
Left Side Panel
Left Side Panel
Right Side Panel
Right Side Panel
Right Side Panel
