Simmons SD9K - External Kit

www.simmonsdrums.net
23
UsethisfeaturewhenyouwanttousethepadsascontrollerstogeneratesoundsfromasoundmoduleotherthantheSD9K’s.The
externalkitallowstheSD9KtotriggerexternaldrumsoundgeneratorsviaMIDIorUSB.InKITmode,whentheExternalKit(00)
isselected,pressingthe[EDIT]buttonenterstheExternalKITEDITmode,forthelastselectedPad.Anotherpadcanbeselectedby
hittingitorpressingitsPadSelectbutton.Additionally,extraMIDIparametersfortheHi-HatnotavailableviathePadSelectbuttons
(Splash,Half-Open,andHalf-OpenRim)canbeselectedbyusingtheHi-HatPedalandhittingtheHi-HatPad.
TherstPadparameteristheMIDINote:
Press the [PAGE DOWN]buttontoaccessthenextparameter,MIDIGate:
NOTE:Sinceinternalvoicesaren’tplayedwhentheExternalKitisselected,
thereisnoMIXmodeforthiskit.
NOTE:AllinternalPresetandUserKitshavexedMIDIgatetimesof0.1s,
andtheMIDInoteofeachtrigisxedasfollows:
TRIG MIDI NOTE
KICK 36
SNARE 38
SNARE R 40
TOM1 48
TOM2 45
TOM3 43
TOM4 41
RIDE 51
RIDE R 53
CRASH1 49
CRASH1 R 55
CRASH2 57
CRASH2 R 52
O HIHAT 46
O HIHAT R 26
C HIHAT 42
C HIHAT R 22
P HIHAT 44
AUX1 17
AUX1 R 18
AUX2 19
AUX2 R 20
SPLASH 21
HALF HIHAT 23
HALF HIHAT R 24
External kit
