11-4
To place the 4100ES FIP into operation, perform the following steps:
STEP 1 Ensure that the Mains Isolate Switch is OFF.
STEP 2 Ensure that 240 VAC is connected to the panel from the mains distribution
switchboard.
STEP 3 Ensure that the Lithium battery is fitted to the battery holder on the CPU
card, and link P3 is fitted to the BAT ON position.
Turn the Mains Switch ON.
STEP 4 Check that the green "MAINS ON" LED indicator on the InfoAlarm user
interface is on.
The Controller performs tests on its memory, electronics, and the LCD.
STEP 5 Check that the buzzer sounds and the LCD displays “CPU Serial Number”.
STEP 6 Check that the LCD has good visibility.
STEP 7 Install and connect the batteries.
Take care not to short the battery leads or connect in reverse polarity when
connecting.
STEP 8 Press the Lamp Test key on the Operator I/F and check that all LEDs turn
on, and the LCD shows all black squares.
STEP 9 Clear all faults one at a time.
A full commissioning test should be carried out as per AS 1670.1. Refer to the appendix
in this manual for detail on checking wiring, and earth fault detection. Refer to the
Operator’s Manual LT0351 for detail of the walk test that may be used for verifying
correct detector operation.
The 4100ES system must be kept free from faults and tested on a regular basis to verify
that it is operating correctly. The tests required by the standard AS 1851 Maintenance of
Fire Protection Equipment are detailed in the 4100ES InfoAlarm Operator’s Manual,
LT0568.
The Operator’s manual also provides detail of report printing and performing tests that are
useful for checking the system.
Power Up & Placing into Operation
Maintenance
