11-3
All the 4100ES cards and modules are tested and aligned in the factory before being
supplied to the customer or fitted to a FIP. The only field adjustment that may be
necessary is to set the battery charger voltage. This has been set and should not need re-
adjusting.
R341 Battery Charger Voltage
Should the battery charger voltage need adjusting, the method is as follows:
1. Run the system with the batteries connected and the door closed for at least 30
minutes to allow components to stabilise.
2. Calculate the required no-load battery charging voltage by taking 27.3V for
20C and subtracting approximately 0.1V for every 3C above 20C, or adding
approximately 0.1V for every 3C below 20C.
3. With the system not in Alarm, disconnect the batteries.
4. Measure the voltage at the battery terminals and adjust to the voltage calculated
in Step 2 by turning pot R341.
5. Re-connect the batteries.
