Simplex 4100ES Installation & Maintenance

G-2
The DC input voltage range of the following modules is 18-33VDC. The current listed is
nominal for 24VDC, and may be used for battery capacity calculations.
Module Name Quiescent Alarm
N/A Master Controller Assembly
(includes SPS, CPU, CPU Motherboard
with RUI I/F, Operator Interface with LCD)
373mA 470mA
4100-6035 Alarm Relay Card 15mA 37mA
4100-3101 IDNet Module without Devices
- per device add
- with 250 devices add
75mA
0.8mA
200mA
115mA
1mA
250mA
4100-1289 64/64 Controller plus Switch LED Modules
- no LED on
- per LED on add
- with 64 LEDs on add
20mA
3mA
210mA
3mA
210mA
4100-0620 Transponder Interface, Basic Unit 87mA 87mA
4100-0625 Transponder Interface, Local Mode 112mA 112mA
4100-6014 Network Interface Card 28mA 28mA
4100-6056 Wired Media Module 55mA 55mA
4100-6057 Fibre Optic Media Module 25mA 25mA
4100-6038 Dual RS232 Interface 132mA 132mA
Voltage & Current Ratings of Modules & Assemblies

Simplex 4100ES Specifications

General

Type	Fire Alarm Control Panel
Display	LCD
Battery Backup	Yes
Model	4100ES
Manufacturer	Simplex
Communication Protocol	Optional Ethernet
Signaling Line Circuits (SLCs)	Up to 10
Notification Appliance Circuits (NACs)	Up to 10
Agency Listings	UL, FM, CSFM, MEA
Max Relay Circuits	20
Communication Ports	Ethernet
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity	Up to 93% RH, non-condensing
