The service port on the door with the Operator Interface enables the 4100ES to connect to
PCs running important utilities, such as diagnostics, programming, CPU firmware
downloading, and channel monitoring.
The recommended connection method is using the Ethernet service port. However, a
serial data connection can be used if the Ethernet option is not available for some reason.
The ES Programmer supports both methods of connection.
Refer to the page number listed in this table for information on a specific topic.
Topic See Page #
Connection and Modes 9-2
Chapter 9
PC Software Connections
Introduction
In this Chapter

Simplex 4100ES Specifications

General

Type	Fire Alarm Control Panel
Display	LCD
Battery Backup	Yes
Model	4100ES
Manufacturer	Simplex
Communication Protocol	Optional Ethernet
Signaling Line Circuits (SLCs)	Up to 10
Notification Appliance Circuits (NACs)	Up to 10
Agency Listings	UL, FM, CSFM, MEA
Max Relay Circuits	20
Communication Ports	Ethernet
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity	Up to 93% RH, non-condensing
