Simplex MAPNET 2 Range – Addressable Field Devices
2190-9156 Mapnet 2 Monitor ZAM
2190-9162 Mapnet 2 Signal ZAM
2190-9164 Mapnet 2 Control ZAM
2190-9169 Mapnet 2 Line Powered Short Circuit Isolator
2190-9172 Mapnet 2 Supervised IAM
2190-9173 Mapnet 2 Loop powered 2 Point Input / Output Module
4099-9032NL Mapnet 2 Addressable Manual Call Point
4099-9701 IDNet Addressable Manual Call Point with LED
4099-9702 IDNet Addressable Manual Call Point without LED
The following lists the detectors approved for use with IDNet and shows current
rating and numbers allowed per loop.
Device Type Operating
Current mA
Maximum
Number Allowed
Per Loop
Maximum
Number
Allowed Per
Line
4098-9714E
Analogue Photoelectric
Smoke Detector
0.5
(2 with LED
on)
250 40*
4098-9717E
Analogue Ionisation
Smoke Detector
0.5
(2 with LED
on)
250 40*
4098-9733E
Analogue Heat Type A &
B Detector
0.5
(2 with LED
on)
250 40*
4098-9754E
Analogue Multi
(Heat/Photo)
Detector
0.5
(2 with LED
on)
250 40*
* Maximum allowed by AS 1670.1.
The above with -9714E, -9717E and -9733E use a (4098-) 9789E addressable
base or -9794E addressable sounder base, or -9793 addressable isolator base.
The -9754E uses a 9796E addressable base or -9795E sounder base.
The maximum specified loop/line resistance is 40.
The maximum number of LEDs switched on by an IDNet in alarm is 20.
List of Approved Devices, Continued
Compatible Detectors, IDNET

Simplex 4100ES Specifications

General

Type	Fire Alarm Control Panel
Display	LCD
Battery Backup	Yes
Model	4100ES
Manufacturer	Simplex
Communication Protocol	Optional Ethernet
Signaling Line Circuits (SLCs)	Up to 10
Notification Appliance Circuits (NACs)	Up to 10
Agency Listings	UL, FM, CSFM, MEA
Max Relay Circuits	20
Communication Ports	Ethernet
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity	Up to 93% RH, non-condensing
