Simplex 4100ES Installation & Maintenance

G-1
System Capacity 2,000 points of addressable points, plus 2,000 points of
annunciation. Expansion up to capacity above.
Up to 119 Addressable cards
Cabinet Size Dependent on system configuration
Cabinet Material 1.6mm Zintec
Cabinet Finish Powder coated
Cabinet Colour Cream Wrinkle
Mounting Wall mount
Mains Input 240V AC, +6%, -10%, 50Hz
Internal Power Supply 24V DC @ 9A
Standby Battery 24V sealed lead acid up 110Ah
Battery Charger 27.3V DC (nominal)
PSU Supervision Charger high/low, Battery low/fail
Temperature -5C to 45C
Humidity 10% to 90% RH non-condensing
Alarm Relay Card:
F1 Alarm, 3A, 15 x 5mm, Glass Cartridge
F2 Supervisory, 3A, 15 x 5mm, Glass Cartridge
F3 Trouble, 3A, 15 x 5mm, Glass Cartridge
Fused Distribution Board (if fitted):
F1 24V Out, 1A 20 x 5mm Glass Cartridge
F2 24V Out, 1A 20 x 5mm Glass Cartridge
F3 24V Out, 1A 20 x 5mm Glass Cartridge
F4 24V Out, 1A 20 x 5mm Glass Cartridge
 WALK TEST System Test.
 4 Operator Access Levels.
 Event Historical Logging.
 Device selectable Alarm Verification.
 Individual Zone Isolate.
 Addressable device disable/enable.
 Non-volatile Flash EPROM for field editable program changes.
 Expansion cards firmware upgraded via download to flash EPROMs.
Appendix G
4100ES Specifications
General
Fuses
Firmware Features

Simplex 4100ES Specifications

General

Type	Fire Alarm Control Panel
Display	LCD
Battery Backup	Yes
Model	4100ES
Manufacturer	Simplex
Communication Protocol	Optional Ethernet
Signaling Line Circuits (SLCs)	Up to 10
Notification Appliance Circuits (NACs)	Up to 10
Agency Listings	UL, FM, CSFM, MEA
Max Relay Circuits	20
Communication Ports	Ethernet
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity	Up to 93% RH, non-condensing
