Simplex 4100ES User Manual

27
1. Press the MENU key to enter the panel’s menu system.
2. Press the NEXT key until the alphanumeric display reads as follows:
3. Press ENTER. The display reads as follows:
4. Press the NEXT key to scroll through the categories of points until the appropriate category is
shown. Press the ENTER key. The first point in the selected category appears. In the
example below, the point shown is the first one in the monitor zone category.
5. Press the NEXT key to scroll through the list of points in the category. When the point that
you want to select is displayed, press ENTER.
21BSelecting Points from the Menu
81BProcedure
Press <NEXT> or <PREVIOUS> to scroll
Select a List of Points?
Press ENTER to select a list of points
All Monitor Zones?
MONITOR CARD 1 ZONE NUMBER 1
FIRE MONITOR ZONE NORMAL

Simplex 4100ES Specifications

General

Type	Fire Alarm Control Panel
Display	LCD
Battery Backup	Yes
Model	4100ES
Manufacturer	Simplex
Communication Protocol	Optional Ethernet
Signaling Line Circuits (SLCs)	Up to 10
Notification Appliance Circuits (NACs)	Up to 10
Agency Listings	UL, FM, CSFM, MEA
Max Relay Circuits	20
Communication Ports	Ethernet
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity	Up to 93% RH, non-condensing
