Simplex 4100+ Guide

Page 10 of 60
1.1.2.1 Card Missing/Failed
Description:
The circuit card is not communicating correctly with the panel controller.
Possible causes:
 Card has not been fitted
 Card is not seated correctly on connector
- Power down panel, clean connectors and reinsert
 Card has not been addressed correctly
 Card DIP Switch incorrectly set (Dipswitch 1 always in ON position)
 Another card has been addressed the same as this card
 Card has failed
1.1.2.2 Correct Card Abnormal
Description:
The wrong type of card has been addressed at this location.
Possible causes:
 Incorrect card fitted in the panel.
 Two cards have the same address.
1.1.2.3 Short Circuit Abnormal
Description:
The addressable loop has a short circuit or the + and – wires are crossed over.
Possible causes:
 If there are no isolators fitted or the short is between the panel and the isolator then the loop will stop
operating. This may also display a channel fail
 Find the short circuit and fix – disconnect the loop totally, check each pair for a short circuit with a
Multimeter. If fault evident continue these checks at half way points around loop until short is
narrowed down
 If short circuit cannot be detected with a Multimeter, disconnect one side of the loop only and
disconnect devices at half way points until the short circuit fault clears, to narrow down the fault
location.
NOTE: Panel will need to be reset between each disconnection as this fault will latch

Simplex 4100+ Specifications

General

Type	Addressable Fire Alarm Control Panel
SLC Loops	Up to 10
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity Range	10% to 93% non-condensing
Display	LCD
Communication	Ethernet
Power Supply	120/240 VAC, 50/60 Hz
Battery Backup	24 VDC
NAC Outputs	Expandable
Releasing Capability	Yes, with releasing modules
Max Notification Appliance Circuits (NACs)	Varies by modules
Max Releasing Circuits	10
Communication Ports	Ethernet
Max Devices	3, 000
