Page 28 of 60
2.3 4100-Family General Crash Codes Table (continued)
CRASH_SMPL_CODE_OPCODE
<Invalid CODE Operation>
CLASS P CRASH
Invalid operation code exists in
program
Invalid operation code exists in program
CRASH_RAM_OVERLAP
<Overlapping CFIG RAM>
CLASS E CRASH
This indicates that the system RAM and the CFIG RAM
addresses overlap. This can be caused by an improper version of
the GEN_INFO.DAT file being on the CC/Build and/or Runtime
Disk.
CRASH_MSGLIB_FMT
<MSGLIB Format Error>
CLASS E CRASH
- Message library format number is incorrect for system software
revision
- Wrong MSGLIB on programmer disk.
Use same programmer version to burn upper and lower EXEC
chips
CRASH_SMALL_RAM
<System RAM chip too small>
CLASS E CRASH
System RAM chip is too small
- The amount of RAM installed in the Master Controller is too
small for the job configuration. Replace the 256K RAM with
1MEG RAM chip on 4100 and 4020, or add an additional RAM
Bank on 4100+ and UT.
- The panel did not have a RAM chip installed into U35. Remove
the chip that had been placed into the CFIG RAM socket U45
and install in the system RAM socket U35
CRASH_INVALID_MSGLIB_NUMBER
<INVALID Msglib Number>
CLASS S CRASH
INVALID Message Library Number
INVALID Message Library Number
