1.1.2.3.4 Extra Device
Description:
A device is located on the addressable loop that is addressed at a location that is not programmed.
Possible causes:
The panel has identified a device/card at an address that is not in the panel programming. Refer to the Extra
Device section of Device Faults (Page 20).
A card/device may be incorrectly addressed bringing up an Extra Device fault and the programmed device‟s
address will display “Points defined but not inserted.”
1.1.2.3.5 IDNet Dipswitch Settings
1. Devices are supplied with DIPSWITCH switch ALL ON (set to 0)
2. DIPSWITCHES are labeled 1 to 8
 Switch 1 = MUST BE ON (OFF disables card communications)
 Switch 2 = 64
 Switch 3 = 32
 Switch 4 = 16
 Switch 5 = 8
 Switch 6 = 4
 Switch 7 = 2
 Switch 8 = 1
3. Turn Switch OFF to add the above number to the address.
Examples:
 Address 5 = Switch 6 & 8 OFF all others ON.
 Address 23 = Switch 4, 6, 7 & 8 OFF others ON.
NOTE - This is reverse of how the addressable devices addresses’ are set.
[Refer to section 1.1.3.9 – page 19]

Simplex 4100+ Specifications

General

Type	Addressable Fire Alarm Control Panel
SLC Loops	Up to 10
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity Range	10% to 93% non-condensing
Display	LCD
Communication	Ethernet
Power Supply	120/240 VAC, 50/60 Hz
Battery Backup	24 VDC
NAC Outputs	Expandable
Releasing Capability	Yes, with releasing modules
Max Notification Appliance Circuits (NACs)	Varies by modules
Max Releasing Circuits	10
Communication Ports	Ethernet
Max Devices	3, 000
