Simplex 4100+ Guide

Page 14 of 60
1.1.3.1.2 Head Missing
Description:
The panel is seeing the base at the displayed address but is not seeing the head (Sensor).
Possible causes:
 Head is not installed.
 Head is not fully twisted onto the base
 Detector terminals on the base are loose
 Faulty Head
 Faulty Base
Suggested solutions:
NO
NO
YES
Replace Head
Adjust terminals to
make better contact
with head
Is base LED
flashing?
Replace Base

Simplex 4100+ Specifications

General

Type	Addressable Fire Alarm Control Panel
SLC Loops	Up to 10
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity Range	10% to 93% non-condensing
Display	LCD
Communication	Ethernet
Power Supply	120/240 VAC, 50/60 Hz
Battery Backup	24 VDC
NAC Outputs	Expandable
Releasing Capability	Yes, with releasing modules
Max Notification Appliance Circuits (NACs)	Varies by modules
Max Releasing Circuits	10
Communication Ports	Ethernet
Max Devices	3, 000
