Simplex 4100+ Guide

Page 15 of 60
1.1.3.1.3 Wrong Device
Description:
The panel is getting a response from the displayed address that does not match the device programmed to
that address.
Possible causes:
 Incorrect device installed (Relay with T-Sense fitted instead of standard Relay)
 Incorrect head installed (Photo instead of Heat)
 Detector head not making good contact with base
Suggested solutions:
NO
YES
Replace Device /
Sensor
Retrieve the part number from the
device (409x-xxxx)
Device or Program
change will be required
Replace Base
Contact the Programmer
to confirm device
matches Program

Simplex 4100+ Specifications

General

Type	Addressable Fire Alarm Control Panel
SLC Loops	Up to 10
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity Range	10% to 93% non-condensing
Display	LCD
Communication	Ethernet
Power Supply	120/240 VAC, 50/60 Hz
Battery Backup	24 VDC
NAC Outputs	Expandable
Releasing Capability	Yes, with releasing modules
Max Notification Appliance Circuits (NACs)	Varies by modules
Max Releasing Circuits	10
Communication Ports	Ethernet
Max Devices	3, 000
