Simplex 4100+ Guide

Page 8 of 60
1.4 Index – Quick view
Loop Card Faults
 Card Missing Failed (Card Inserted)
 Correct Card
 Short Circuit
 Class A
 Channel Failure
 Channel Initialization
 Extra Device
 Card DIP Switch
Addressable Device Faults
 No Answer
 Head Missing
 Wrong Device
 Bad Answer
 Extra Device
 Output Abnormal
 Detector LED Operation
 Device LED Operation
 DIP Switch Table
 End of Line Resistor Values.
 Hints & Tips
NOTE - It is vital that the Loop card is in
NORMAL status before addressable
device fault finding is started.
!

Simplex 4100+ Specifications

General

Type	Addressable Fire Alarm Control Panel
SLC Loops	Up to 10
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity Range	10% to 93% non-condensing
Display	LCD
Communication	Ethernet
Power Supply	120/240 VAC, 50/60 Hz
Battery Backup	24 VDC
NAC Outputs	Expandable
Releasing Capability	Yes, with releasing modules
Max Notification Appliance Circuits (NACs)	Varies by modules
Max Releasing Circuits	10
Communication Ports	Ethernet
Max Devices	3, 000
