Simplex 4100+ Guide

Page 19 of 60
 Devices are supplied with DIPSWITCH set to 255
 DIPSWITCHES are labeled 1 to 8 (left to right)
 Switch 1 = 1
 Switch 2 = 2
 Switch 3 = 4
 Switch 5 = 8
 Switch 6 = 16
 Switch 7 = 32
 Switch 8 = 128
 Turn Switch ON to add the above number to the address. Examples:
 Address 10 = Switch 2 & 5 ON all others OFF
 Address 105 = Switch 1, 4, 6 & 7 ON others OFF
 The highest IDNet device address is 250.
 The highest MAPNet device address is 127.

1.1.3.1.10 End of Line Resistors
For a comprehensive pocket reference guide contact your local Simplex® branch
4090-9001
Supervised IAM
Current Limited
6.8kΩ
4.7kΩ & 1.8kΩ
4090-9101
Monitor ZAM
3.3kΩ
4090-9118
Relay IAM with T-Sense
Current Limited
6.8kΩ
4.7kΩ & 1.8kΩ
4090-9120AU
6 Pt I/O Module
Current Limited
6.8kΩ
4.7kΩ & 1.8kΩ
2190-9156
Mapnet Monitor ZAM
3.3kΩ
2190-9164
Mapnet Signal ZAM
10kΩ
4100 EWIS
WIPs
10kΩ
4100 8pt Monitor Card
Conventional Zone Card
3.3kΩ
4100 6 Signal Card
Signal Card
10kΩ
4100 24-pt IO Card
Pluggable Resistors on card
2.2kΩ Input
20Ω Output

Simplex 4100+ Specifications

General

Type	Addressable Fire Alarm Control Panel
SLC Loops	Up to 10
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity Range	10% to 93% non-condensing
Display	LCD
Communication	Ethernet
Power Supply	120/240 VAC, 50/60 Hz
Battery Backup	24 VDC
NAC Outputs	Expandable
Releasing Capability	Yes, with releasing modules
Max Notification Appliance Circuits (NACs)	Varies by modules
Max Releasing Circuits	10
Communication Ports	Ethernet
Max Devices	3, 000
