CP42/50/52 Installation and service Chapter 10
111
10.3 Installation of CP52 DGPS Chartplotter
The CP52 can be flat or bracket mounted – overhead*, bulkhead* or console.
Console mounting
*Overheadandbulkhead
mounting is only possible if
using a distance piece.
20 (0.8)
196 (7.7)
75 (3.0)
88.8 (3.5)
131.6 (5.2)
391.6 (15.4)
433.9 (17)
460 (18.1)
9.2 (0.4)
330 (13)
