CP42/50/52 Fundamentals & initial start-up Chapter 2
14
_7_
SETUP
_1_ Speed alarm, units & language
_2_ NMEA interface
_3_ Alarm/log output
_4_ Decca lanes
_5_ Loran C
_6_ Display color
_7_ Factory settings
When selecting a sub-menu in the SETUP
menu, the display will always appear in a pop-
up window. Which means that it will not take
the place of another display, and it will not mess
up the pre-set displays on the screen.
And once you have confirmed the changes, or
just want to exit the display, the display will
disappear from the screen, as you have no
further use for it.
2.5 Choice of symbols
Waypoints and other points appearing on the screen can be marked by
one of 18 symbols + 8 EVENT marks in small and large symbols:
Waypoint
Red buoy
Green buoy
Wreck
Danger
Beacon
Fish
Platform
Rock awash
Harbour
Marker
North
South
East
West
Starboard
Port
MOB
EVENT 4
(1 of 8 types in
diamond shape)
