CP42/50/52 NAV menus & navigation examples Chapter 6
66
Navigation setup:
Anchor alarm distance: 00.50nm
WP circle alarm: 00.10nm OFF
WP and cursor navigation:
XTE alarm: 00.10nm OFF
Navigation mode: RHUMBLINE
Route navigation:
XTE alarm: OFF
Auto waypoint shift: WP-circle
Track navigation:
XTE alarm: 00.10nm OFF
Auto trackpoint shift: WP-line
Navigation mode: RHUMBLINE
+/-
Toggle between available values, or…
0-9
key in a new alarm limit
ENT
Confirm entry
Anchor alarm distance – When setting the anchor it is possible to set
up an alarm at the same time, so you will be warned in case you drift
too far from the anchored position. The alarm distance can be set to
anywhere from 0.01 to 9.99nm.
The alarm will automatically be reset once you are inside the limits
again.
WP circle alarm – forms a circle around each waypoint, and the alarm
distance can be set to anywhere between 0.01 and 9.99nm.
The waypoint alarm will be activated when you reach the circle or the
perpendicular line – WP line alarm – crossing through the waypoint.
When “Auto waypoint shift” is set to “WP-circle” it will override the
“WP circle alarm” function.
XTE alarm – forms a corridor along the ideal track. When crossing
one of the boundaries the XTE alarm will be activated.
The alarm will automatically reset once you are inside the limits again.
The alarm distance can be set to anywhere between 0.01 and 9.99nm.
) In Route navigation the XTE alarm value can be specified for each
route leg – see section 5.2.
