CP42/50/52 Chart menus and INFO windows Chapter 3
23
3.3.2 Cursor active but not placed on any object or data
ENT
With chart in active window, and cursor not placed on any object or
user data, press
[ENT]
to call up an info window with the following to
choose from:
Scale: 1:6600000
-Actual chart scale.
No user data
at cursor position
1
Edit user data
-Inactive function.
2
Chart info
-Refer to Appendix C.
3
Find nearest port services
-Refer to Appendix C.
4
Bearing & dist. from A to B
5
Lock cursors
9
Chart setup
-Refer to section 3.4.
0
Cursor to center
GOTO
Select NAV mode
-Refer to section 3.3.8.
PLOT
Plot new data
-Refer to section 3.3.9.
PAGE
More user data
-Inactive function.
MENU
Exit
-Exit info window.
4
Bearing & dist. from A to B will quickly provide the bearing and
distance from your current cursor position (A) to an arbitrary point (B).
Move cursor to point B and see the calculation in the small info
window. Press
[MENU]
to exit the function.
5
Lock cursors will lock the cursors in two chart displays on the same
screen and thus make the cursor movements synchronized. To return to
individual cursor control in each chart display, press
[ENT]
and
[5]
to
“Release cursors” again.
) See also “Lock cursors” in Appendix A.
0
Cursor to center will adjust the chart to place the cursor position in the
center of the chart display.
