CP42/50/52 Position menus Chapter 4

4.3 Speed, course & depth

Call up the menu bar, and…

2,3

load Speed, course & depth display

Speed over ground

*.*kn

Course

Depth below keel

*.*m

This display is

preset to show:

Speed over ground

in knots.

Magnetic course.

Depth below keel

in meters (via con-

nected sensor).

To change the settings for this display:

• Speed over ground can be changed from the Position display settings

to show Speed through water: Press [MENU], [2], [1], [ENT], go to the

line “Display speed as: SOG”, press the [+] key to toggle to STW,

press [ENT] to accept the change. The top line in above display will

now show Speed through water.

• Course can be shown as magnetic or true. Toggle between the two

settings from the Position display: Press [MENU], [2], [1], [ENT], go

to the line “Course and bearing as: MAGNETIC”,pressthe[+]keyto

toggle to TRUE, press [ENT] to accept the change. The middle part in

above display will now show True course e.g. 17°.

• To obtain a depth readout in this display will require that a depth

sensor is connected. The readout is selected from the Interface setup:

[MENU],[7],[2],goto“Depth” in the Water data section and toggle

betweenDBKDepthBelowKeel,DBTDepthBelowTransducerand

DBS Depth Below Surface, press [ENT], [ENT] to accept the change.

The new setting will be shown in the lower part of the display.
