Simrad EK80 Harbour Acceptance Test

22
401925/C
iMakesurethatallweldsandbracketshavebeenpaintedwiththecorrect
preservationmediumtopreventcorrosion.
4Makesurethattheunitisnotphysicallydamaged,andthatthesurfacesand
paint-workarecleanwithoutdentsorscratches.
Thephysicalhandlingduringtheinstallationmayhavecausedsomeminor
scratchestothesurfacesorpaint-work.Thiscanbeaccepted.However,ifrough
handlinghascausedseriousdamage,thismustberecordedwithawrittenstatement
andnecessaryphotos,sothatcorrectiveactionscanbemade.
5Makesurethattheunitisrmlyconnectedtoship'sground.
aMakesurethattheunitissecurelyconnectedtotheship'sgroundwithan
earthingstrap.Thestrapmustbeinadditiontoanyincidentalelectricalcontact
madebythemountinglugsontheunit.
bUseastandardmultimetertocheckthattheresistancebetweentheunitandthe
ship'sgroundisapproximately0(zero)Ω.
6Makesurethatcableinstallationhasbeencompleted.
aMakesurethatallcablesleadingtoandfromtheunithavebeenproperly
mountedandsecured.
bMakesurethatenoughslackhasbeenprovidedoneachcabletoallowfor
maintenanceandreplacement.
7Makesurethattheunithasbeenidentiedwiththerelevantproductlabel(s),and
thatonelabelincludesthepartandserialnumbers.
Result
Requirements
Results
TheWideBandTransceiver(WBT)iscorrectlyinstalledwitheasyaccess
formaintenanceandreplacementofparts.
TheWideBandTransceiver(WBT)isfreefromscratches,dentsorother
physicaldamage.
FreeaccesstoalltheconnectorsontheWideBandTransceiver(WBT)are
provided.AllcablesconnectedtotheWideBandTransceiver(WBT)are
properlymountedwithenoughslack.
TheweldsandbracketsthatsupporttheWideBandTransceiver(WBT)
arestrongenoughtoholdtheunitsecurelyinplaceunderalloperating
conditions.Theweldsandbracketshavebeenpaintedwiththecorrect
preservationmediumtopreventcorrosion.
TheWideBandTransceiver(WBT)isproperlygrounded.
Dateandsignature:
Relatedtopics
Customeracceptanceform,page46
SimradEK80HarbourAcceptanceTest
