Simrad EK80 Harbour Acceptance Test

56
401925/C
EElapsedTime:Thisistheelapsedtimeofthereplaysequence.
FPlaybackProgress:Thisbarshowsyoutheprogressofthereplaysequence.If
youhavechosentorestartthereplayle(s)automatically(inaloop),thegreen
indicatorstartsfromlefteverytimethelerestarts.
Procedure
1OpentheOperationmenu.
2SetOperationtoReplay.
Thereplaybaropensautomatically.Itispositioneddirectlybelowthetopbaratthe
topoftheEK80presentation.
Ifyouneedtoselectwhichlestoreplay,selectReplayFileundertheOperation
button.Youcanalsoselectthelargebuttoninthemiddleofthereplaybar.
3SelectPlay/Pausetostarttheplayback.
4Tostopthereplaychooseanyotheroperatingmode.
Relatedtopics
TestingtheEK80operationalfunctionality,page27
Secondaryprocedures,page47
Choosingwhichrawdatale(s)toreplay
Everytimeyourecordechodata,theinformationisstoredontheProcessorUnithard
disk.Dependingonyourinitialsettings,thelesmayalsobestoredonaUSBhard
diskorevenanetworkdisk.Theechodatalescanberetrieved,andplayedbackon
theEK80.
Context
Allplaybackiscontrolledbythereplaybar.
AStop:Selectthisbuttontostoptheplayback.Thereplaybarisnotremovedfromthe
presentationuntilyouselectanotheroperatingmode.
BPlay/Pause:Selectthisbuttontostarttheplayback,ortopauseit.
CReplaySpeed:Selectthissliderandmoveitsidewaystoadjustthereplayspeed.
SimradEK80HarbourAcceptanceTest
