Simrad EK80 Harbour Acceptance Test

401925/C
39
8Ifpossible,useanotherinstrumenttoverifythattheinformationprovidedbythe
EK80iscorrect.
9Fillintheresulttables.
Result
SensorSourcesensor
DatagramPortBaudrate
Position
Speed
Distance
Heading
XOffsetYOffsetZOffset
Requirements
Results
Positiondataisprovided.
Speeddataisprovided.
Distancedataisprovided.
Headingdataisprovided.
Therelevantcommunicationparametersarerecorded.
Dateandsignature:
Relatedtopics
Customeracceptanceform,page46
Secondaryprocedures,page47
Verifyingthecommunicationwithspeedlog
Withouttheinputfromaspeedlog,theEK80willnotbeabletopresentcorrect
navigationalinformation.Thevesselspeedisshownonthetopbarifyouhaveenabled
thisintheDisplayOptionsdialogbox.Thecommunicationwiththesensoristested.
Prerequisites
TheEK80isinstalledasspeciedintheEK80Installationmanual.
•ThesensorisconnectedtoacommunicationportontheEK80.Thesensoristurned
onandinnormaloperation.
•Theinterfaceportissetupwiththecorrectcommunicationparameters.
•YouarefamiliarwithNMEAandotherrelevantdatagramformats.
TestingtheEK80operationalfunctionality
