401925/C

cDenethemaximumamountofbytestobecontainedinonedatale.

SelectMaximumfor1GBlesize.

ThecurrentsizeoftheRAWdataleisdisplayedduringdatarecording.Ifthe

currentlesizegetstoobigduringrecording,selectSplitFileontheRecord

RAWbutton.RecordRAWislocatedontheOperationmenu.

dSpecifytherawdatarecordingparameters.

TheRangesettingdenestheverticalorhorizontaldistancefromwherethe

echopresentationstartstotheendofthesearcharea.

•SelectCommontousethesamerecordingrangeforallyouractivechannels.

•SelectAutotoallowtheEK80toautomaticallyndtherequiredrangevalue.

•SelectIndividualtousethedifferentrecordingrangesforyouractive

channels.

TheStoredsampleddataforWBTsrunningCWoptionscanbeusedtoreduce

theamountofrecordeddatawhenyouareusingaWideBandTransceiver

(WBT)withCWpulses.

•SelectComplexsamplestousethedefaultdataformat.

•SelectPower/Angletoreducethelesizes.

•SelectReducedsamplingratePower/Anglesamplestominimizethelesizes.

Note

UnlessyouchooseComplexsamplesyourRAWdataleswillcontainless

information.

TheMotionDataRecordingfunctionallowsyoutocontrolhowoftenthe

motiondataaresavedintherawdatale.

5Atthebottomofthepage,selectApplytosaveyoursettings.

6SelectOKtoclosethedialogbox.

Relatedtopics

TestingtheEK80operationalfunctionality,page27

Secondaryprocedures,page47
