Simrad EK80 Harbour Acceptance Test

62
401925/C
Thisserialnumberisveryimportant,becauseyouwillneeditasareference
identicationwhentheEK80iscalibrated.SomenewSimradtransducerswith
built-in"intelligence"willautomaticallyprovidethisserialnumber.
6TypethenameyouwishtouseintotheCustomNamebox.
Typeanynamethatyouwishtousetoidentifythetransducer.Thenameyouselect
willonlybeusedtoidentifythetransducerinotherdialogboxes.Itisnotusedin
theechodatathatyouexport.Ifyoudonothaveacomputerkeyboardconnectedto
yourEK80system,selecttheKeyboardbuttontoopenanon-screenkeyboard.
7Selectmountingmethod.
8Specifytheorientationofthetransducerbeam.
9Ifrelevantforyourtransducerinstallation,providetheaccuratephysicallocationof
thetransducerwithreferencetothevessel’scoordinatesystem.
Note
ThesesettingsareintendedfortheinstallationofanADCPtransceiverforcurrent
proling.Theinformationisnotusedtoadjustforinstallationmisalignments,but
willbeincludedintheRAWlesforpost-processingpurposes.
Usethecentreofthetransducerfaceasreference,anddenetheoffsetvalues
relatedtotheShipOrigin.
aSelecttheoffsetvalueontheXaxis(fore-and-aftdirection)fromtheShip
Origin.AdjustwithapositivevalueforXifthetransducerislocatedahead
oftheshiporigin.
bSelecttheoffsetvalueontheYaxis(athwartship)fromtheShipOrigin.
AdjustwithapositivevalueforYifthetransducerislocatedonthestarboard
sideoftheshiporigin.
cSelecttheoffsetvalueontheZaxis(vertical)fromtheShipOrigin.Adjust
withapositivevalueforZifthetransducerislocatedundertheshiporigin.
10Ifrelevantforyourtransducerinstallation,providetherotationangles.
Note
ThesesettingsareintendedfortheinstallationofanADCPtransceiverforcurrent
proling.Theinformationisnotusedtoadjustforinstallationmisalignments,but
willbeincludedintheRAWlesforpost-processingpurposes.
aObtaintherotation(angle)informationfromthepersonnelthatinstalledthe
transducer.
bInsertthevalues.
•Specifyanangle(indegrees)tocompensateforanydeviationfromtheX
axis(fore-and-aftdirection)inthecoordinatesystem.
•Specifyanangle(indegrees)tocompensateforanydeviationfromthe
y-axis(athwartshipdirection)inthecoordinatesystem.
SimradEK80HarbourAcceptanceTest
