SPOOL PINS AND SPOOL CAPS
Yourmachinehastwospoolpins,amainspoolpinandanauxiliaryspoolpin.Thespoolpinsaredesignedforalltypesofthread.
Themainspoolpinisadjustableandcanbeusedinahorizontalposition(thethreadreelsoffthestationaryspool)orinavertical
position(thethreadspoolrotates).Usethehorizontalpositionforallregularembroiderythreadsandtheverticalpositionforlarge
spools or specialty threads.
Auxiliary Spool Pin
Theauxiliaryspoolpinisusedwhenwindingabobbinfroma
secondspoolofthread.
Lifttheauxiliaryspoolpinupandtotheright.Slideonaspool
cap.Forspoolssmallerthanthemediumsizespoolcap,place
afeltpadunderthethreadspooltopreventthethreadfrom
reelingofftoofast.Forlargerspools,thefeltpadshouldnotbe
used.
Horizontal Position
Liftthespoolpinupslightlyfromitshorizontalpositionto
easily place the thread spool on the pin. The thread should reel
overthetop,inacounterclockwisedirection,asshowninthe
picture.Slideonaspoolcapandthenmovethespoolpinback
tothehorizontalposition.
Eachmachinecomeswithtwospoolcapsonthespoolpin.
Formediumsizedthreadspools,themediumsizedcap(A)is
placedinfrontofthespool.Forlargethreadspools,thelarge
cap(B)isplacedinfrontofthespool.
Theatsideofthespoolcapshouldbepressedrmlyagainst
thespool.Thereshouldbenospacebetweenspoolcapand
thread spool.
Asmallspoolcapisincludedasanaccessoryforyourmachine.
The small spoolcapcanbeusedforsmallthreadspools.
Note: Not all thread spools are manufactured in the same
way. If you experience problems with the thread, turn it in the
opposite way or use the vertical position.
Vertical Position
Liftthespoolpinupandallthewaytotheright.Lockthe
spoolpinintheverticalpositionbyslightlypressingitdown.
Slideonthelargespoolcap.Forspoolssmallerthanthe
mediumsizespoolcaporwhenusingspecialtythreads,place
a feltpadunderthethreadspooltopreventthethreadfrom
reelingofftoofast.Forlargerspools,thefeltpadisnotneeded.
Note: No spool cap should be placed on top of the spool as this
prevents the spool from rotating.
Note: When the spool pin is used in the vertical position, the
thread tension might need to be adjusted manually.
