4:2
A
B
C
F
E
D
5
2
1
3
4
EMBROIDERY UNIT OVERVIEW
(type BE19)
1. Embroidery unit release button (underside)
2. Embroidery arm
3. Embroidery hoop attachment
4. Level adjustment feet
5. Embroidery unit socket
EMBROIDERY HOOP OVERVIEW
A Embroidery hoop connector
B Outer hoop
C Inner hoop
D Quick release
E Retaining screw
F Center marks
BUILT-IN DESIGNS
150 designs and 1 embroidery font in three sizes are built into
the memory in your machine.
SINGER
®
EM9305 SAMPLER BOOK
On www.singer.com you can nd the SINGER
®
EM9305
Sampler book. Here you can see all the designs and fonts that
are built into the machine.
The design number, stitch count (number of stitches in the
design) and the design size are displayed next to each design.
The suggested thread color for each color block is shown.
When removing the embroidery unit from the
box for the rst time, be sure the shipping brace
on the underside of the embroidery unit has been
removed.
