REPAIR
0607SE Maintenance Manual 6-19 © Jan 2022
Note: some interfaces can only be accessed with a
password (the password can only be provided to
personnel professionally trained and authorized by
Sinoboom).
Update program
1. Prepare a 4-32GB USB flash disk, and format its file
system into FAT32 format.
2. Upload the ECU program to the root directory of the
USB flash disk: ECU_MAIN.bin.
Note: please contact Sinoboom after-sales
personnel to get the program.
3. Turn off the machine, and insert the USB flash disk
into the program updating port (protected by a
rubber plug) at the back of ECU.
4. Press and hold the Esc key on the ECU panel while
powering up the machine. Release the Esc key 5s
after power-on, and the program will be updated
automatically.
5. After the program is updated, power off the
machine.
Checking program version
After entering the ECU menu selection mode, enter
System settings interface, and select System version to
check the current program version.
User selection
• Users can select the country, driver and model of
the machine in the User selection menu of
Parameter debugging.
• The parameters (weight, height, level gauge and
handle) of the machine can be calibrated in the User
selection menu of Parameter debugging.
• The lithium battery of the machine can be
configured (if necessary) in the User selection menu
of Parameter debugging.
System parameters
In the System parameters menu of Parameter
debugging, the up limit switch, down limit switch, pit
protection switch, lowering delay switch, outdoor mode
configuration, weighing device, angle sensor, level
inclination switch, function keys, level angle sensor,
walk limit on pit, standby function, double pressure
configuration, single pressure configuration, down
overload restraint, horn configuration, GPRS
communication configuration, foot switch configuration,
anti-collision switch configuration and 80/90 overweight
alarm can be switched on or off.
Warning parameters
In the Warning parameters menu of Parameter
debugging, the parameters of level gauge X-axis
warning, level gauge Y-axis warning, raised/stowed
shift point, allowable overload lowering height, walk
limit height, low battery capacity alarm value, low
voltage alarm value, standby time, drive motor current
limit, pump motor current limit, deceleration time 1 and
deceleration time 2 can be set.
Note:
• The input angle setting value needs to be multiplied
by 10 times. For example, if the input value is 20,
the actual angle value is 2°.
• The height setting value is in decimeter (dm).
• The battery capacity setting value is in %.
• The voltage setting value is in volts (V).
• The setting value of low voltage alarm time is in
seconds (s), and the setting value of standby time is
in minutes (min).
Motion parameters
In the Motion parameters menu of Parameter
debugging, the motion parameters of lifting motion,
lowering motion, steering motion, raised travel speed,
high speed (stowed) and low speed (stowed) can be
set.
Query Interface
In the Query Interface, users can query the GPS
information service, PCU information service, battery
pack information, Curtis driver information and trouble
code of the machine (for the causes and solutions of
trouble codes, please refer to Trouble Diagnosis ,
page 6-26).
Country selection
1. After entering the ECU menu selection mode, select
and enter the Country selection interface, then
select the desired country through PgUp key and
PgDn key, and press the Enter key for confirmation.
2. Select one country to open the corresponding
configuration of the country. See the table below for
the configuration of each country.
Item China
Europe &
America
Korea
Japan
Single/double
pressure
OFF
Double
pressure
Double
pressure
Double
pressure
Outdoor mode
ON (depend on
models)
ON ON ON
