Fig 2 Home interface after booting
Table 10-1
1. Home 4. OK button
7. Right shift key/next page
2. State monitor/next page 5. Down shift key 8. Setting
3. Left shift key 6. Up shift key
9. Faults
10.3 STATE MONITOR
1. On the Home interface, press the State Monitor but-
ton to enter the Machine State (1/3) interface.
To Next Page
