Sinoboom AB16EJ Plus - Technical Characteristics; Machine Specifications

AB16EJ Plus Maintenance Manual 11
© Mar. 2023
3 TECHNICAL CHARACTERISTICS
3.1 MACHINE SPECIFICATIONS
Table 3-1 Specifications
ITEM
Metric Imperial
Product Category
Power type Battery
Outrigger type Oscillating outrigger
DIMENSION
Max. platform height
15.8m 51ft 10in
Max. working height
17.8m 58ft 5in
Max. horizontal reach
(250kg/340kg/454kg)
9m/8.1m/7m 29ft 6in/26ft 7in/23ft
Max. horizontal working envelope
(250kg/340kg/454kg)
9.6m/8.7m/7.6m 31ft 6in/28ft 7in/24ft 11in
Overall length (stowed)
7.6m 24ft 11in
Overall length (transport)
6.1m 20ft
Overall width (stowed)
2.3m 7ft 7in
Overall width (transport)
2.3m 7ft 7in
Overall height (stowed)
2.25m 7ft 5in
Overall height (transport)
3.1m 10ft 2 in
Wheelbase 2.3m 7ft 7in
Ground clearance 0.37m 1ft 3in
Max. up and over height
7.9m 25ft 11in
Platform dimension (L×W×H)
Options
1.45×0.85×1.1m
1.83×0.85×1.1m
Options
4ft 9in×2ft 9in×3ft 7in
6ft×2ft 9in×3ft 7in
PERFORMANCE
Rated platform capacity
250kg (unrestricted)/340kg
(restricted)/454kg (restricted)
551lb (unrestricted)/750lb
(restricted)/1000lb (restricted)
Max. number of allowed people on
the platform (restricted/unrestricted)
3 persons/2 persons
Drive speed (stowed)
0～5.5km/h
0～3.4mph
Drive speed (raised)
0～1.1km/h
0～0.68mph
Gradeability (4WD)
40%
Turntable rotation (angle/continuity)
355°/non-continuous
Platform rotation angle
180°
