TECHNICAL CHARACTERISTICS
AB16EJ Plus Maintenance Manual 13
© Mar. 2023
Table 3-1 Specifications(Continued)
ITEM
Metric Imperial
Storage environment
Stored at -20℃ to 50℃ (-4℉ to 122℉) in a well-ventilated environment with
90% relative humidity (20℃ [68℉]), and away from rain, sun, corrosive
gas, inflammables and explosives.
Note:
a) The platform height plus the operator height (taken as 2m [6ft 7in]) is the working height.
b) The maximum horizontal reach plus the arm length of the operator (taken as 0.6m [1ft 11in]) is the maximum
horizontal working envelope.
c) The ground bearing data is approximate, without considering different options, thus it is applicable only in
adequately safe conditions.
d) In different areas, hydraulic oil, engine oil, coolant, fuel and lubricant should be added in accordance with the
environmental temperature.
e) In cold weather, auxiliary devices are needed to start the machine.
f) Rated platform load capacity refers to the maximum allowable load on the platform, including the weight of
persons, materials, tools, accessories and other objects.
g) It’s recommended not to use the lead-acid battery under the ambient temperature below 0℃, otherwise the
battery capacity will decay rapidly and the battery life will be affected.
3.2 SPECIFICATIONS OF MAJOR
COMPONENTS
Motor
Table 3-2 Travel motor (PN.203010003107)
Model
JXQ-2-2B
Rated power 2kW
Rated voltage 32V
Rated current 50A
Rated RPM 1733rpm
Rated
frequency
60Hz
Rated torque
20Nm (14.75ft-lb)
Table 3-3 Hybrid motor (PN.203010003108)
Model
JXQD-7-4B
Rated power 7kW
Rated voltage 32V
Rated current 165A
Rated RPM 3333rpm
Rated
frequency
114Hz
Rated torque
20Nm (14.75ft-lb)
Reducer
Table 3-4 Slewing reducer (PN.204020000015)
Model
SE17-102-25H-R-1037
Type Worm gear reducer
Output torque
(Max.)
10000Nm (7375ft-lb)
Output RPM ＜2.5rpm
Tipping
moment (Max.)
135600Nm (100005ft-lb)
Holding
moment
72300Nm (53321ft-lb)
Reduction ratio 102:1
Table 3-5 Travel reducer (PN.204020003019)
Model IFT007T2062
Maximum
output torque
7000Nm (5163ft-lb)
Rated output
torque
3500Nm (2581ft-lb)
Maximum input
torque
112Nm (82.6ft-lb)
Maximum input
RPM
4000rpm
Speed ratio
62.33
